Easy Sand Line kit, DIY pool kit 4 x 7 x h 1.50, skimmer overflow sand filter

EASYBLOK SYSTEM

Thanks to this innovative system, building a reinforced concrete swimming pool is easy, fast, and economical.

Rectangular pools can be built, easily equipped by inserting inlets, skimmers, and lights directly into the walls of EPS (a material with "closed-cell" technology, unlike common polystyrene, which guarantees a high degree of resistanceto water and humidity infiltration that leads to the degradation of the material's structural characteristics).

The available formats meet every construction need, while guaranteeing unparalleled ease of installation: it is sufficient to connect the interlocking modules, taking care to reinforce each line of formwork. Afterwards, the concrete is poured inside the formwork to create a real reinforced concrete wall.

Straight modules: 1.25 m long, 30 cm high.
Specifications: PS30 density, estimated cement quantity: 0.12 m³ x m².

The simplicity of assembling the structure is surprising.

Excavation, concrete, and iron are excluded.

The innovative SKIMMER SFIORATORE system

Overflow skimmer with very wide suction mouth (approx. 80 cm width, 7 cm height) for reinforced concrete pools with PVC lining.

Allowed flow rate: from 6 to 10 mc/h.
Material: Made of UV-resistant ABS with wide mouth.
Positioning: Near the edge (up to 8 cm from the pool edge).

Equipment (Outlets and Connections):
- n.1 threaded outlet Ø 2’M
- 1 gluing outlet Ø 50
- Overflow Ø 40
- Level regulator connection Ø 40

Recommendations: installation of an automatic level regulator is recommended.

POOL FEATURES:

Shape Rectangular
Type Skimmer
Length 7m
Width 4m
Structure height 1.5m
Water height 1.40 m as per law
Surface 28m²
Perimeter 22m
Volume 42m³

N.B.: The filtration system is supplied unassembled

On base: € 749.00
In technical room: € 1,499.00
In technical room with bypass: € 1,999.00

Accessories and Integrations

Level control: complete with pipes and additional accessories (€ 499.00 extra).
Bluetooth electrical panel: allows starting and stopping the filtration system and lighting via smartphone app, without accessing the physical panel.

Lighting Customization
It is possible to replace the PAR56 lamps included in the kit with tubular lamps. Design lighting kits can be integrated with these to increase the light points:

- Small: +2 tubular lamps
- Medium: +4 tubular lamps
- Large: +6 tubular lamps

Please note: Add the cost of the service before adding the product to the cart.

DETAILS ON THE LINING (PVC SHEET)

Standard shades: white, sand, basalt gray and medium gray (to be specified when ordering).
Other shades: available upon request by contacting us directly via e-mail or telephone.

The PVC sheet supplied in our kits will make your pool elegant and perfectly finished. This lining has a special lacquer that makes it super smooth, resistant to chlorine, UV rays and atmospheric agents, thus preserving the beauty and vibrancy of the color. Furthermore, it is durable over time thanks to the special polyester reinforcement placed in the center of the various layers that compose it. Cleaning operations are also reduced because the liner is anti-limescale and resistant to attack by sun creams and any microorganisms (fungi/bacteria/spores).

Notes for Installation: it is necessary to heat-seal the sheet on site using a leister or a heat gun.

Customization: Stair or Beach entry
It is possible to customize the pool by choosing between two different access solutions:

- The STAIR is a pre-assembled block, easy and quick to install.
Supplied with plastic-coated corners for a perfect sheet laying. Supplied with a coil of non-slip reinforced PVC sheet for safety.
- The BEACH entry on the other hand, needs to be assembled on site. Supplied with plastic-coated corners for a perfect sheet laying. Supplied with a coil of non-slip reinforced PVC sheet for safety. Suitable for creating a beach entry with a maximum size of 10sqm.
