Easy Sand Line kit, DIY pool kit 6 x 10 x h 1.50, skimmer overflow sand filter

EASYBLOK SYSTEM

Thanks to this innovative system, building a reinforced concrete pool is easy, fast, and economical.

Rectangular pools can be created, easily accessorized by inserting jets, skimmers, and lights directly into the walls of EPS (a material with "closed-cell" technology, unlike common polystyrene, it guarantees a high degree of resistance to water infiltration and humidity that lead to the degradation of the material's structural characteristics).

The available formats meet every construction need, while ensuring unparalleled ease of installation: it is sufficient to interlock the modules, making sure to reinforce each line of formwork. Subsequently, a concrete pour is carried out inside the formwork to create a true reinforced concrete wall.

Straight modules: length 1.25 m, height 30 cm.
Specifications: Density PS30, estimated concrete quantity: 0.12 m³ x m².

The simplicity of assembling the structure is surprising.

Excavation, concrete and iron are excluded.

The innovative OVERFLOW SKIMMER system

Overflow skimmer with a very wide suction mouth (approx. 80 cm wide, 7 cm high) for reinforced concrete pools with PVC lining.

Admissible flow rate: from 6 to 10 m³/h.
Material: UV-resistant ABS with a wide mouth.
Positioning: Near the edge (up to 8 cm from the pool edge).

Equipment (Outlets and Connections):
- n.1 2'M threaded outlet
- 1 Ø 50 glue outlet
- Ø 40 overflow
- Ø 40 level regulator connection

Recommendations: installation of an automatic level regulator is recommended.

POOL CHARACTERISTICS:

Shape Rectangular
Type Skimmer
Length 10m
Width 6m
Structure height 1.5m
Water height 1.40 m as required by law
Surface 60m²
Perimeter 32m
Volume 90m³

N.B.: The filtration system is supplied unassembled

On base: € 749.00
In technical room: € 1,499.00
In technical room with by-pass: € 1,999.00

Accessories and Integrations

Level control: complete with pipes and completion accessories (€ 499.00 additional).
Bluetooth electrical panel: allows you to start and stop the filtration system and lighting via a smartphone app, without accessing the physical panel.

Lighting Customization
It is possible to replace the PAR56 lamps included in the kit with tubular lamps. Design lighting kits can be integrated with these to increase the light points:

- Small: +2 tubular lamps
- Medium: +4 tubular lamps
- Large: +6 tubular lamps

Please note: Add the service cost before adding the product to the cart.

DETAILS ON THE LINING (PVC SHEET)

Standard shades: white, sand, basalt grey and medium grey (to be specified when ordering).
Other shades: available on request by contacting us directly via email or phone.

The PVC sheet provided in our kits will make your pool elegant and perfectly finished. This lining has a special lacquer that makes it super smooth, resistant to chlorine, UV rays and atmospheric agents, thus preserving the beauty and vibrancy of the color. Furthermore, it is durable over time thanks to the special polyester reinforcement placed in the center of the various layers that compose it. Cleaning interventions are also reduced because the liner is anti-limescale and resistant to attack from sun creams and any microorganisms (fungi/bacteria/spores).

Installation Notes: it is necessary to heat-weld the sheet on site using a leister or a heat gun.

Customization: Ladder or Beach Area
It is possible to customize the pool by choosing between two different access solutions:

- The LADDER is a pre-assembled block, easy and quick to install.
Supplied with plasticized corners for a professional sheet laying. Supplied with a coil of non-slip safety reinforced PVC sheet.
- The BEACH AREA , on the other hand, is to be assembled on site. Supplied with plasticized corners for a professional sheet laying. Supplied with a coil of non-slip safety reinforced PVC sheet. Suitable for creating a beach area with a maximum size of 10sqm.
