Easy Sand Line kit, DIY pool kit 6 x 9 x h 1.50, skimmer overflow sand filter

EASYBLOK SYSTEM

Thanks to this innovative system, building a reinforced concrete pool is easy, fast, and economical.

Rectangular pools can be created, easily accessorized by inserting inlets, skimmers and lights directly into the walls of EPS (a material with "closed-cell" technology, unlike common polystyrene, guarantees a high degree of resistance to water infiltration and humidity that lead to the degradation of the material's structural characteristics).

The available formats meet every construction need, while ensuring unparalleled ease of installation: it is enough to couple the interlocking modules, taking care to reinforce each formwork line. Subsequently, concrete is poured inside the formwork to create a real reinforced concrete wall.

Straight modules: 1.25 m long, 30 cm high.
Specifications: PS30 density, estimated cement quantity: 0.12 m³ x m².

The simplicity of assembling the structure is surprising.

Excavation, concrete, and rebar are excluded.

The innovative SKIMMER SFIORATORE system

Overflow skimmer with a very wide suction mouth (approx. 80 cm wide, 7 cm high) for reinforced concrete pools with PVC lining.

Permitted flow rate: 6 to 10 mc/h.
Material: Made of ABS, UV-resistant with a wide mouth.
Positioning: Close to the edge (up to 8 cm from the pool edge).

Equipment (Outlets and Connections):
- No. 1 threaded outlet Ø 2’M
- 1 gluing outlet Ø 50
- Overflow Ø 40
- Level regulator connection Ø 40

Recommendations: installation of an automatic level regulator is recommended.

POOL CHARACTERISTICS:

Shape Rectangular
Type Skimmer
Length 9m
Width 6m
Structure height 1.5m
Water height 1.40 m as per law
Surface 54m²
Perimeter 30m
Volume 81m³

N.B.: The filtration system is supplied unassembled

On base: € 749.00
In technical room: € 1,499.00
In technical room with by-pass: € 1,999.00

Accessories and Integrations

Level control: complete with pipes and additional accessories (€ 499.00 extra).
Bluetooth electrical panel: allows starting and stopping the filtration system and lighting via a smartphone app, without accessing the physical panel.

Lighting Customization
It is possible to replace the PAR56 lamps included in the kit with tubular lamps. Design lighting kits can be integrated with these to increase the light points:

- Small: +2 tubular lamps
- Medium: +4 tubular lamps
- Large: +6 tubular lamps

Please note: Add the service cost before adding the product to the cart.

DETAILS ON THE LINING (PVC SHEET)

Standard shades: white, sand, basalt gray and medium gray (to be specified at the time of order).
Other shades: available on request by contacting us directly via email or phone.

The PVC sheet supplied in our kits will make your pool elegant and perfectly finished. This lining has a special lacquer that makes it super smooth, resistant to chlorine, UV rays, and atmospheric agents, thus preserving the beauty and vibrancy of its color. Furthermore, it is durable over time thanks to the special polyester reinforcement placed in the center of its various layers. Cleaning operations are also reduced because the liner is anti-limescale and resistant to attack by sunscreens and any microorganisms (fungi/bacteria/spores).

Notes for Installation: it is necessary to heat-weld the sheet on site using a leister or a heat gun.

Customization: Stairs or Beach Area
It is possible to customize the pool by choosing between two different access solutions:

- The STAIRS are a pre-assembled block, easy and quick to install.
Supplied with plasticized corners for perfect liner laying. Includes a coil of non-slip reinforced PVC liner for safety.
- The BEACH AREA must be assembled on site. Supplied with plasticized corners for perfect liner laying. Includes a coil of non-slip reinforced PVC liner for safety. Suitable for creating a beach area of up to 10sqm.
