Astralpool wide-mouth ABS skimmer 17.5 Lt for PVC liner pool

Version for swimming pools with prefabricated panels or reinforced concrete with PVC liner.

Wide-mouth skimmer for surface water suction. Equipped with a floating weir that allows skimming only the surface layer of water, regardless of the water level in the pool.

Supplied with adhesive gaskets, flanges, screws, sandwich gasket, and square cover.
Made of white ABS with UV treatment for parts that are not buried. Supplied with floating weir and cap for flow rate adjustment.
Leaf basket secured at the base by a bayonet lock.
Recommended flow rate 7.5 m3/h.

Lower suction connection: 11/2” internal thread, 2” external.
Simultaneous connection to bottom drain: Ø 50 mm internal.
Upper connection for overflow Ø 40 mm.

It is recommended to install one skimmer for every 25 m² of water surface.
